CKSC series harmonic Wave filter reactor Filtration effectively absorb the harmonic waves, improve the voltage wave,
and power factor.The products used in the power system of 0-63KV and below, series connected with the system,
to eliminate voltage distortion, and improve theelectric quality and ensure safe operation of thepower system,
limit the short current when systemhas fault. The products operates in substations ofpower system, electric railway,
metallurgy, chemicalindustry, petroleum, and other places where highflameproof level, electromagnetic immunity isrequired, or installation place is limited.
Characteristics:
1. Improve voltage distribute on each line
2. Balance reactive power when overload circuit ,reduce power loss on the line
3.When the reactor neutral grounding via small reactor device,Also available small reactor
compensation line and phase to ground capacitance,to accelerate the arc current automatically extinguished, easy to Install.
